UCP 205 Bearing Specifications
Pillow Block Ball Bearings No.
Shaft Dia
Dimensions(mm)
d
mm
h
a
e
b
S1
S2
UCP 205
25
36.5
140
105
38
13
19
Pillow Block Ball Bearings No.
Shaft Dia
Dimensions(mm)
d
mm
g
w
n
Bi
Weight
UCP 205
25
15
71
14.3
34.1
0.75
Pillow Block Ball Bearings No. | Shaft Dia | Dimensions(mm) | |||||
d | |||||||
mm | h | a | e | b | S1 | S2 | |
UCP 205 | 25 | 36.5 | 140 | 105 | 38 | 13 | 19 |
Pillow Block Ball Bearings No. | Shaft Dia | Dimensions(mm) | |||||
d | |||||||
mm | g | w | n | Bi | Weight | ||
UCP 205 | 25 | 15 | 71 | 14.3 | 34.1 | 0.75 |
UCP 205 pillow block ball bearings materials of ferrules and steel ball accessories
Bearing rings and steel balls are generally made of SUS420, SUS440, SUS304, SUS316 and other stainless steel materials. The cage is generally made of SUS304, nylon 66, engineering plastics, and polytetrafluoroethylene. The dust cover is made of stainless steel SUS430, SUS304 and other materials. It is stamped and its chemical composition is shown in Table 1.
Table 1:
UCP 205 Material Type
Stainless steel material type | C | Cr | Si |
SUS420J2 (3Cr13) | ≤0.6 | ≤0.6 | ≤0.6 |
SUS440 (9Cr18) | ≤0.6 | ≤0.6 | ≤0.6 |
SUS440C (95Cr18Mo) | 0.95-1.2 | 16-18 | ≤1 |
SUS304 (0Cr18Ni9) | ≤0.03 | 18-20 | ≤1 |
SUS316(0Cr17NiMo2) | ≤0.03 | 16-18 | ≤1 |
Stainless steel material type | Mn | S | P |
SUS420J2 (3Cr13) | ≤1 | ≤0.03 | ≤0.035 |
SUS440 (9Cr18) | ≤0.8 | ≤0.03 | ≤0.035 |
SUS440C (95Cr18Mo) | ≤1 | ≤0.03 | ≤0.04 |
SUS304 (0Cr18Ni9) | ≤1 | ≤0.03 | ≤0.045 |
SUS316(0Cr17NiMo2) | ≤1 | ≤0.03 | ≤0.045 |
Stainless steel material type | Mo | Ni | |
SUS440 (9Cr18) | ≤0.6 | ||
rgba(255, 255, 255, 1) | ≤0.075 | ≤0.6 | |
SUS440C (95Cr18Mo) | 0.40-0.65 | ≤0.75 | |
SUS304 (0Cr18Ni9) | 8-11 | ||
SUS316(0Cr17NiMo2) | 2-3 | 10-14 |
Wholesale UCP 205 | UCP 205 Supplier
Welcome to UCP 205 manufacturer– NSAR, your trusted UCP 205 pillow block ball bearings factory in wholesale UCP 205 pillow block ball bearing! As leading UCP 205 pillow block bearing manufacturer in the bearings industry, we take immense pride in providing top-quality UCP 205, including UCP 202,UCP 203. NSAR offers a wide range of UCP 205 at the most competitive prices,which will provide you with a great shopping experience.
