Nuestros cojinetes de almohada termoplásticos son una alternativa premium a los cojinetes metálicos tradicionales. Diseñados con materiales termoplásticos de alto rendimiento, estos rodamientos ofrecen excelente durabilidad, resistencia a la corrosión y facilidad de mantenimiento, lo que los hace ideales para una amplia gama de aplicaciones industriales.
Our Plastic pillow block UCF bearings combine the corrosion-resistant properties ofthermoplastic housingswith the rugged design of UCF-style four-bolt flange bearings. These bearing units are designed to provide reliable shaft support in environments where conventional metal bearings may fail due to moisture, chemicals or hygienic requirements. Their design ensures easy installation, maintenance-free operation and suitability for a wide range of industrial applications.
Rodamientos de bloque de almohada de plástico
Plastic pillow block bearings feature housings made from high-performance thermoplastics that provide superior mechanical strength and dimensional stability. Unlike metal bearings, these bearings are inherently resistant to rust and corrosion, making them ideal for food processing, pharmaceuticals and other industries with stringent hygienic standards. The self-lubricating properties of plastic housings eliminate the need for external lubrication, reducing maintenance requirements and operating costs. In addition, plastic construction is lightweight without compromising durability.
UCF Bearings
UCF bearings are four-bolt flange bearing units designed to provide rugged shaft support. They consist of an insert bearing with an extended inner ring that is typically secured to the shaft using set screws. The square flange design allows for easy installation and alignment, accommodating shaft misalignment and reducing installation time. UCF bearings are used across a wide range of industries for their versatility and reliability.
Features include pre-lubricated bearings for ready installation, grease fittings for relubrication, and bonded seals for wet or dirty environments.
Resistencia a la corrosión
Fabricados con materiales termoplásticos avanzados, nuestros cojinetes de almohada son altamente resistentes a la corrosión. Esto los hace ideales para su uso en entornos húmedos o químicamente agresivos, como aplicaciones de procesamiento de alimentos, farmacéuticas y marinas.
Construcción ligera
AINELos cojinetes de almohada termoplásticos son significativamente más livianos que los cojinetes de metal. Esta construcción liviana permite un fácil manejo e instalación, lo que reduce los costos de mano de obra y aumenta la eficiencia operativa.
Propiedades autolubricantes
Las propiedades autolubricantes de los materiales termoplásticos reducen la necesidad de lubricación adicional, minimizan los requisitos de mantenimiento y garantizan un funcionamiento más suave y eficiente. Esta característica es particularmente beneficiosa en entornos donde la limpieza es fundamental.
Reducción de vibraciones y ruidos
The inherent properties of thermoplastics help absorb vibrations and reduce noise, resulting in quieter, smoother operation. This is particularly beneficial in applications such as medical devices, office machinery, and home appliances.
Chemical and UV resistance Our thermoplastic bearings are resistant to a wide range of chemicals and UV radiation and are therefore suitable for both indoor and outdoor applications. This resistance ensures long-lasting functionality even in harsh environmental conditions.
Tipo | diámetro del agujero | diámetro del agujero | Peso de la carcasa (kg) | Bull.fiss. Tamaño del perno |
Tipo | d | d | Peso de la carcasa (kg) | Bull.fiss. Tamaño del perno |
Tipo | en | milímetros | Peso de la carcasa (kg) | Bull.fiss. Tamaño del perno |
UCFBPL 201 | 1/2 | 12 | 0.1 | M10 |
UCFBPL 202 | 9/16 5/8 | 15 | 0.1 | M10 |
UCFBPL 203 | 16/11 | 17 | 0.1 | M10 |
UCFBPL 204 | 3/4 | 20 | 0.1 | M10 |
UCFBPL 205 | 13/16 7/8 15/16 1 | 25 | 0,12 | M10 |
UCFBPL 206 | 1-1/16 1-1/8 1-3/16 1-1/4 | 30 | 0,16 | M10 |
UCFBPL 207 | 1-1/4 1-5/16 1-3/8 1-7/16 | 35 | 0,18 | M12 |
UCFBPL 208 | 1-1/2 1-9/16 | 40 | 0,23 | M12 |
Tipo | Dimensiones (mm) | Dimensiones (mm) | Dimensiones (mm) | Dimensiones (mm) | Dimensiones (mm) |
Tipo | a | mi | h | w | s |
UCFBPL 201 | 62 | 38.1 | 76,5 | 108,5 | 11 |
UCFBPL 202 | 62 | 38.1 | 76,5 | 108,5 | 11 |
UCFBPL 203 | 62 | 38.1 | 76,5 | 108,5 | 11 |
UCFBPL 204 | 62 | 38.1 | 76,5 | 108,5 | 11 |
UCFBPL 205 | 63,5 | 41.3 | 85,7 | 120,6 | 11 |
UCFBPL 206 | 75 | 47,6 | 98,5 | 140 | 11 |
UCFBPL 207 | 89 | 50,8 | 110 | 158 | 13 |
UCFBPL 208 | 78 | 50 | 114 | 164 | 13 |
Tipo | Dimensiones (mm) | Dimensiones (mm) | Dimensiones (mm) | Dimensiones (mm) | Dimensiones (mm) |
Tipo | F | do | b | I | gramo |
UCFBPL 201 | 22.2 | 42,9 | 62 | 26,5 | 12 |
UCFBPL 202 | 22.2 | 42,9 | 62 | 26,5 | 12 |
UCFBPL 203 | 22.2 | 42,9 | 62 | 26,5 | 12 |
UCFBPL 204 | 22.2 | 42,9 | 62 | 26,5 | 12 |
UCFBPL 205 | 28.6 | 46 | 69 | 33,5 | 12 |
UCFBPL 206 | 31,8 | 52,4 | 82 | 31,5 | 14 |
UCFBPL 207 | 31,8 | 60.3 | 94 | 36,5 | 17 |
UCFBPL 208 | 41.3 | 60.3 | 100 | 35,7 | 18 |
Tipo | Dimensiones (mm) | Dimensiones (mm) | Dimensiones (mm) |
Tipo | i | norte | Bi |
UCFBPL 201 | 15.4 | 12.7 | 31 |
UCFBPL 202 | 15.4 | 12.7 | 31 |
UCFBPL 203 | 15.4 | 12.7 | 31 |
UCFBPL 204 | 15.4 | 12.7 | 31 |
UCFBPL 205 | 21 | 14.3 | 34.1 |
UCFBPL 206 | 19 | 15.9 | 38.1 |
UCFBPL 207 | 21.4 | 17,5 | 42,9 |
UCFBPL 208 | 21.4 | 19 | 42,9 |
Modo de carga
Modo de carga |
Capacidades de carga (N) Capacidades de carga (N) | Capacidades de carga (N) Capacidades de carga (N) | Capacidades de carga (N) Capacidades de carga (N) | Capacidades de carga (N) Capacidades de carga (N) | Capacidades de carga (N) Capacidades de carga (N) |
Tipo Tipo | 204 | 205 | 206 | 207 | 208 |
UCFBPL |
7200 | 9100 | 12200 | 12900 | 13600 |
UCFBPL |
9200 | 11100 | 11800 | 11900 | 12100 |
UCFBPL |
2600 | 2800 | 2900 | 3100 | 3300 |
